Fibre Channel is the Recommended Storage Technology for the Brownfield vSphere Deployment

Given the constraints of the brownfield site, the existing infrastructure, and the approved budget, the architect should recommend leveraging the existing Fibre Channel storage technology.

Here's the reasoning based on the provided requirements:

Utilize Existing Storage Array:The crucial constraint is that the budget is only for new server and network hardware, explicitly excluding the purchase of a new storage array. The solutionmustutilize the existing storage array.

Existing Fibre Channel Connectivity:The current storage array is already connected via Fibre Channel with a dedicated SAN fabric (2 x 8 Gbps interfaces). This existing infrastructure can be directly leveraged with new servers equipped with Fibre Channel HBAs.

Budget Alignment:Reusing the existing Fibre Channel SAN aligns with the budget approval for only new server and network hardware (to connect the servers to the existing SAN). Introducing a different storage technology like iSCSI or NFS as the primary method would likely require significant network infrastructure changes or additions beyond standard server networking, which may not be covered by the approved budget for "new server and network hardware only." While the arraycansupport NFS, the existing high-speed, dedicated storage connectivity is Fibre Channel.

Incompatibility with vVols:The existing storage array does not support vSphere API for Storage Awareness (VASA), which is a mandatory requirement for implementing vSphere Virtual Volumes (vVols). Therefore, vVols is not a viable option with the current storage hardware.

vSAN Not Applicable to Existing Array:VMware vSAN is a software-defined storage solution that pools local storage from ESXi hosts. It does not directly utilize external Fibre Channel SAN arrays as its primary storage pool in the standard configuration. Implementing vSAN would require a significant investment in server local storage, which falls outside the scope of using theexisting storage array.

Manageability:The existing vSphere administration team is responsible for operational management. Fibre Channel storage is a mature and commonly used storage technology in vSphere environments, meaning the existing team is likely to have the necessary skills to manage it.

While the existing arraycanbe configured for NFS, leveraging the existing Fibre Channel connectivity is the most direct and budget-aligned approach given that the SAN fabric and FC interfaces are already in place and the budget is restricted to server and network hardware for connectivity.

Creating a separate vSphere cluster for management workloads ensures that these workloads, which are critical for monitoring, managing, and orchestrating the environment, do not compete for resources with compute workloads. This separation enhances the stability and reliability of management functions, even during periods of high resource utilization by compute workloads.

Six 10TB VMFS datastores will be configured on each site for all production workloads.

This choice is based on the need to distribute production workloads across multiple datastores while ensuring that each datastore is large enough to accommodate the space required by the workloads. Given the average sizes of the virtual machines and the growth and snapshot overhead, six 10TB VMFSdatastores would be appropriate for production workloads, ensuring scalability while minimizing the number of LUNs.

Each 10TB LUN will be configured as a VMFS datastore.

VMFS (Virtual Machine File System) is the standard choice for vSphere environments when using Fibre Channel LUNs. It provides the necessary features, such as concurrency and high-performance access, for production workloads. This option is appropriate given that the storage array uses Fibre Channel for connection and VMFS is the standard file system for such configurations.

Two 10TB VMFS datastores will be configured on each site for all DMZ workloads.

The DMZ workloads are smaller in number and storage requirements compared to the production workloads, so configuring two 10TB VMFS datastores for DMZ workloads will provide enough capacity while maintaining logical isolation. This approach also minimizes the number of LUNs required to meet the storage growth needs.
