Review the exhibit.
As the frame traverses from **PC-1** to **Server-1**, the VLAN tag will be removed.
Click on the interface (circled in green) where the VLAN tag will be removed.
Click on the colored box that corresponds with the line that best represents Multicast traffic flow.
What command displays information regarding the secondary image installed on an AOS-CX switch?
Review the exhibit.
Which ports should be configured as access ports? Click in the green box to make your selection. (Select two.)
Match each network protocol to the correct server listening port. Not all answers will be used.
Currently, the prompt on the AOS-CX switch displays:
Core-1(config)# interface 1/1/1
_Core-1 (config-if)#_
What command will immediately return the prompt to privileged mode?
Refer to the exhibit.
All four switches in the diagram have been configured with the region name "Aruba1".
What two other MSTP configurations must match for switches within the same MST region? (Choose two.)
What are two mechanisms supported on AOS-CX 6300 switches used in Multi-active Detection to determine the status of the Primary member? (Choose two.)
What is the process where a compute device converts logical data bits into the correct physical representation depending on the media?
Core#configure terminal
Core(config)#vrf Green
Core(config-vrf)#exit
Core(config)#
Core(config)#interface vlan 50
Core(config-if-vlan)#?
Given the configuration on theCOREswitch shown above, what command would follow to assign the switched virtual interface (SVI) vlan 50 to the VRF created?
Which command will save your configuration on an AOS-CX switch so that your changes automatically load on next reboot?
ServiceOS login:admin
SVOS>password
Enter password:********
Confirm password:********
The login password to access an Aruba AOS-CX was lost. After connecting to the switch console port, a reboot is performed and the Service OS console is accessed as shown above.
What is the default password that is required for the admin account while under the Service OS console?
Refer to the exhibit.
The above scenario shows a packet from the Server destined for the Firewall. Switch-A and Switch-B are bundled as VSF stack. The LAG between the VSF stack and the firewall indicates a hash function to forward the packet on port 2/1/2.
Which statement is true regarding how Switch-A will forward the packet?
What is the login and password combination is used when first configuring an Aruba OS-CX switch from factory defaults?
What are two methods for remotely managing an Aruba AOS-CX switch? (Choose two.)
You have completed a successful VSF stack between two switches.
Without manually assigning a backup switch, what is the expected output when issuing a show vsf command?
Refer to the exhibit.
You are in the process of configuring VSF between Access-1 and Access-2. Access-1 has been configured as the VSF Master.
What is a valid configuration for Access-2 to join the VSF stack?
