Understanding Automation Processes in FortiAnalyzer:

FortiAnalyzer can automate responses to detected security events, such as running commands on FortiGate devices.

Analyzing the Customer Requirement:

The customer wants to run a CLI command on FortiGate to block predefined URLs when a botnet C & C server IP is detected.

This requires an automated response triggered by a specific event.

Evaluating the Options:

Option A: Playbooks orchestrate complex workflows but are not typically used for direct event-triggered automation processes.

Option B: Data selectors filter logs based on criteria but do not initiate automation processes.

Option C: Event handlers can be configured to detect specific events (such as detecting a botnet C & C server IP) and trigger automation stitches to execute predefined actions.

Option D: Connectors facilitate communication between FortiAnalyzer and other systems but are not the primary mechanism for initiating automation based on log events.

Conclusion:

To start the automation process when a botnet C & C server IP is detected, you must use an Event handler in FortiAnalyzer.

Based on the analysis of the Triggering Events and the Raw Message provided in the FortiSIEM 7.3 interface:

Active Reconnaissance (A): The " Triggering Events " table shows a single source IP (10.200.3.219) attempting to connect to multiple different destination IP addresses (10.200.200.166, .128, .129, .159, .91) on the same service (FTP/Port 21). Each attempt consists of exactly 1 Sent Packet and 0 Received Packets. This pattern of " one-to-many " sequential connection attempts is the signature of a horizontal port scan, which is a primary technique in Active Reconnaissance.

Destination hosts are not responding (C): The Raw Log shows the action as " timeout " and specifically lists " sentpkt=1 rcvdpkt=0 " . In FortiGate log logic (which FortiSIEM parses), a " timeout " with zero received packets indicates that the firewall allowed the packet out (Action was not ' deny ' ), but no SYN-ACK or response was received from the target host within the session timeout period. This confirms the destination hosts are either offline, non-existent, or silently dropping the traffic.

Why other options are incorrect:

FortiGate is not routing (B): If the FortiGate were not routing the packets, the logs would typically not show a successful session initialization ending in a " timeout, " or they would show a routing error/deny. The fact that 44 bytes were sent indicates the FortiGate processed and attempted to forward the traffic.

FortiGate is blocking return flows (D): If the return flow were being blocked by a security policy on the FortiGate, the action would typically be logged as " deny " for the return traffic, and the session state would reflect a policy violation rather than a generic session " timeout " .

In FortiAnalyzer 7.6 and related SOC versions, incidents serve as centralized containers for tracking and analyzing security events. There are two primary automated and manual methods to initiate an incident:

Using a custom event handler (A): In FortiAnalyzer, event handlers are used to generate events from raw logs.1 A critical feature in recent versions is the Automatically Create Incident setting within a custom event handler.2 When enabled, the system automatically elevates a triggered event into a new incident record, allowing analysts to bypass the manual review of every individual event before an incident is raised.3

By running a playbook (D): Playbooks provide a powerful way to automate the incident lifecycle.4 A playbook can be configured with an Event Trigger, meaning it executes as soon as an event matches specific criteria. One of the core actions available within these playbooks is the Create Incident action, which can automatically populate incident details, severity, and category based on the triggering event ' s data.5 This ensures high-fidelity events are consistently captured for investigation.

Why other options are incorrect:

Using a connector action (B): While connectors allow FortiAnalyzer to communicate with external systems (like ITSM or Security Fabric devices), the act of " creating an incident " inside FortiAnalyzer is a function of the internal event engine or playbook automation, not a standalone connector action used for external integration.

Manually, on the Event Monitor page (C): While you can view, filter, and acknowledge events on the Event Monitor page, the process of manually raising an incident typically occurs from the Incidents module or by right-clicking an event to " Raise Incident " in the Log View or FortiView, rather than being a core function defined as occurring " on the Event Monitor page " in the same architectural sense as handlers and playbooks.
